F56 Charge Pipe Lite

Key Highlights

Product: F56 Charge Pipe Lite — Increased Air Flow, More Rugged Boost System Upgrade
Compatibility: BMW transverse engines B37, B38, B46, B47, B48
OEM Reference: Replaces part numbers 11618511338 and 11614753651
Benefits: Stronger design prevents leaks and boost loss
Performance: Larger caliber with 3-ply silicone couplers for durability

Product Overview

We've received a lot of feedback from BMW transverse engine owners about the OEM charge air line (part numbers 11618511338 or 11614753651), which comes with a single-layer silicone hose that is quite soft and thin.

When engine RPM increases, the hose contracts, reducing airflow and eventually causing cracks and leaks. This leads to a drop in boost pressure.

That's why we've introduced the Charge Pipe Lite — a standalone product that delivers the same boost effect at a more cost-effective price.

Key Features

Increased airflow and boost stability
Direct OEM replacement with larger caliber
3-ply silicone couplers for durability
Bung included for water injection
Prevents hose blowouts
Easy to install by yourself or with a dealer

Suitable for a wide range of gasoline and diesel models, including B38, B37, B48, B47, and more.

Contents

FTP silicone hose, clamp, C-clip, and O-ring (all included in the kit).

Fitment

Part #sg71381-C is compatible with the following vehicles:

1' F40 (05/2018 – 12/2019)
1' F52 (10/2015 – 12/2019)
2' F44 Gran Coupé (10/2018 – 12/2019)
2' F45 Active Tourer (11/2013 – 04/2018)
2' F45 Active Tourer LCI (04/2017 – 12/2019)
2' F46 Gran Tourer (07/2014 – 03/2018)
2' F46 Gran Tourer LCI (05/2017 – 12/2019)
X1 F48 (11/2014 – 07/2019)
X1 F48 LCI (05/2018 – 01/2020)
X1 F49 (11/2014 – 08/2019)
X1 F49 LCI (05/2018 – 12/2019)
X2 F39 (10/2016 – 12/2019)
MINI F56 (04/2013 – 12/2019)
MINI F55 (09/2013 – 12/2019)
MINI Clubman F54 (11/2014 – 07/2019)
MINI Clubman F54 LCI (05/2018 – 12/2019)
MINI Cabrio F57 (11/2014 – 12/2019)
MINI Countryman F60 (11/2015 – 01/2020)
Zinoro M13 (06/2015 – 08/2019)

Note: Not applicable to MINI GP and 306HP versions.
